SkyWalker 2316 Motor D28.8 x 32mm 1250kV 41A/615W/54s

Hobbywing HW30415051 - SkyWalker 2316SL 1250Kv Outrunner High power & High performance The newly designed 2312, 2316, and 2320 fixed-wing motors have increased output power. The propeller mounting provides greater torque compared with competing motors of the same specification. The maximum output power is approximately 10% higher. Excellent heat dissipation design The large hollow design, combined with the self-dissipating structure of the top cover, enhances the cooling capacity and prolongs the lifespan of the motor. Higher dynamic balance requirements Adopts an excellent production and assembly dynamic balance technology with high-quality bearing and high-precision CNC machining, it provides an extremely low dynamic balance of the rotor to reduce motor vibration and provide smoother operation. Multi-anti-loosening rotor design After installing the copper pad and retainer spring on the core of the rotor shaft, the bushing and set screw help secure the rotor and improving the reliability of the motor. Excellent materials Top branded JNEH1200 silicon steel sheet, 0.2mm thick material, provides lower iron loss. N48 strong magnetic arc magnetic steel design provides maximum torque output for the motor. 180°C high temperature resistant enameled wire, enhances the high temperature resistance of the stator coil. Silicone wire outlet, which is softer and easier to route than the traditional straight outlet silicone wire. Included Accessories: Propeller Adapter Assembly Motor mounting plate Screws Specs: Recommended Battery: 3-4S LiPo KV Rating: 1250KV No-load Current: 1.7A/14.8V Winding Resistance: 38.5mΩ Number of slot poles: 12N14P Maximum continuous current: 41A/54s Maximum continuous power: 615W/54s Motor Size: D28.8xL34mm Motor Weight: 79g Shaft Diameter: 4mm Bearing model: 684ZZ（OD9xiD4xT4mm) Phase cable: 18AWG Cable length: 100mm Recommended ESC: Skywalker-V2 30-50A Recommended Propellers: 3S: 9x4.5E，10x5E, 10x6E / 4S: 7x6E，8x6E Clip mounting hole threads: D12mm-3xM2.5 Base threads: D16mm-2xM3 / D19mm-2xM3
